Reynaers Aluminium has launched Vision 7, a high usage anti-finger trap thermal commercial door and framing system.
The system, featuring a 40mm radius bulb-style and a profile sightline of 81mm, and achieving a U-value as low as 1.1W/m2K, Vision 7 has a post-installation adjustable bottom pivot that allows installers to make final adjustments.
The door can be manufactured up to 3m height and 120Kg weight with 1.25m leaf width.
UK product development manager Ian Osborne said: “To maximise value and minimise waste, profiles are supplied in a range of optimised bar lengths including 5.1m, optimal for doors up to 2.5m height. Many profiles are available in half and quarter lengths, and for large doors up to 3m mullions and door styles are available at optimal 6.1m or 6.5m lengths. Transom connections are cut straight to minimise milling and the number of components required.
“In addition, the system can be supplied with a range of universal fixation pieces that provide a simple slide and turn solution and ensure that the stock requirements of the system are minimised. There are also many hardware solutions for this system, but we have sourced and tested two key industry suppliers that provide the quality and value suited to the Vision 7 solution.
“We have also developed a new style bulb with a radius of only 40mm to enable the production of slim profile doors with a visual width of only 81mm, which in combination with a wide range of finite component details, enables the production of extremely durable doors that can achieve a U-value of 1.4W/m2K with double glazing units and a lower value of 1.1W/m2K with triple glazing. The system can support glass thickness up to 50mm. Standard and HI variants are available. We also supply a 100mm outer frame so that the system can connect seamlessly to MasterLine 8 windows and doors.”
